Muck-pile behavior plays a pivotal role in optimizing mining operations, as post-blast throw, drop, and lateral dispersion directly influence equipment selection and loading efficiency. The present study conducted a series of novel blasting trials to systematically evaluate the effects of different blast design parameters on key muck-pile characteristics. Principal Component Analysis (PCA) was employed to determine the most influential design variables for developing optimized blast configurations. The investigation comprised multiple combination blasts executed in four distinct phases at the OC1 RGIII mine of SCCL. Blast layouts were precisely developed using advanced blasting software and implemented in accordance with the parameters identified through PCA. Muck-pile properties were quantified using advanced AI-based analytical tools, yielding detailed and reliable insights.The findings revealed that a spacing-to-burden ratio of 1.35, stemming length equal to 0.9 times the burden, 1 m decking, and a V-pattern initiation sequence produced superior muck-pile conditions. This optimized configuration resulted in a reduction of drop by 3 m, a decrease in throw by 5.9 m, and an increased lateral spread of 19.3 m. These improvements contributed to smoother loader manoeuvrability, enhanced loading efficiency, and overall operational optimization.

In this study, UAVs played a crucial role in capturing high-quality muck-pile photographs, which were essential for characterizing key blast results such as drop, throw, and lateral spread. Principal Component Analysis (PCA), performed using XLSTAT, was instrumental in identifying and selecting the most influential blast design parameters affecting the blast outcomes. AI tool was effectively used to design blasts based on insights derived from the baseline study and PCA results A special AI tool within Strayos software was also utilized, which is unique in its ability to characterize key blast parameters, including throw, drop, and lateral spread. The results from this study unequivocally demonstrate that the V-firing pattern is the optimal choice for controlled rock fragmentation and efficient excavation. This results in well-sized fragments with a 3-meter drop, 5.9-meter throw, and 19.3-meter lateral spread, improving muck- pile stability and operational efficiency. The spacing-to-burden ratio of 1.35 optimizes energy distribution, balancing vertical drop (5 meters) with enhanced lateral spread (21 meters). This ratio reduces vertical energy dissipation, improving fragmentation and operational efficiency. A decking length of 1 meter further enhances performance by concentrating explosive energy in a smaller vertical zone, ensuring controlled fragmentation and a stable muck-pile. These findings underline the importance of combining the V-firing pattern, spacing-to-burden ratio of 1.35, and 1m short decking lengths to achieve the most efficient and economical blast design. Such an approach not only improves excavation efficiency but also contributes to the economic viability of the operation by minimizing the need for secondary blasting and optimizing loading cycles. The reduced vertical drop and enhanced lateral spread allow for efficient rock displacement, improving the overall productivity of the mining operation and reducing the operational costs associated with excavation and loading. Future research will focus on expanding the methodology to deeper benches and different rock types, integrating real-time blast monitoring, and developing AI-based decision tools capable of predicting muck-pile characteristics prior to blasting at mine-wide scale. This will enable continuous optimization of blasting operations, allowing dynamic adjustment of design parameters to further enhance productivity and sustainability in mining operations.

[1]Choudhary, B. S. (2019). Effect of blast induced rock fragmentation and muckpile angle on excavator performance in surface mines. Mining of Mineral Deposits, 13(3), 119-126. [2]Zou, D., & Zou, D. (2017). Explosives. Theory and Technology of Rock Excavation for Civil Engineering, 105-170. [3]Xu, P., Yang, R., Zuo, J., Ding, C., Chen, C., Guo, Y., … & Zhang, Y. (2022). Research progress of the fundamental theory and technology of rock blasting. International Journal of Minerals, Metallurgy and Materials, 29(4), 705-716. [4]Ouchterlony, F. (2003). Influence of blasting on the size distribution and properties of muckpile fagments: a state-of-the-art review. [5]Liu, Q., Shi, F., Wang, X., & Zhao, M. (2022). Statistical Estimation of Blast Fragmentation by Applying 3D Laser Scanning to Muck Pile. Shock and Vibration, 2022. [6]Brunton, I., Thornton, D., Hodson, R., & Sprott, D. (2003). Impact of blast fragmentation on hydraulic excavator dig time. Fifth Large Open Pit Mining Conference, 39-48. [7]Monjezi, M., Rezaei, M., & Yazdian Varjani, A. (2009). Prediction of rock fragmentation due to blasting in Gol-E-Gohar iron mine using fuzzy logic. International Journal of Rock Mechanics and Mining Sciences, 46(8), 1273–1280. https://doi.org/10.1016/j.ijrmms.2009.05.005 [8]Rai, P. (2002). Evaluation of effect of some blast design parameters on fragmentation in open cast mine. Ph.D. thesis, Banaras Hindu University, Varanasi. [9]McKenzie, C.K. (1999). A review of the influence of gas pressure on block stability duringrockblasting, Procs. Explo-99, Kalgoorlie, WA, pp: 173-179. [10]Stagg, M.S., Otterness, R.&Siskind, D.F.(1992).Effects of blasting practices on fragmentation ,Rock Mechanics, Titherson Ed., Balkema, Rotterdam, pp:313-322. 33rd U.S. Symposium on Rock Mechanics (USRMS), Santa Fe, New Mexico, June 1992. Paper Number: ARMA-92-0313 Published: June 03. [11]Adamson,W.R., Scherpenisse,C.R.& Diaz,J.C.(1999).The use of blast monitoring modeling technology for the optimization of development blasting, Proc.Explo-99,Kalgoolie,WA, pp: 35- 41. [12]Kanchibotla,S.S.,Valery,W.&Morrell,S.(1999).Modelling fines in blast fragmentation and its impact on crushing and grinding,Procs.Explo-99,Kalgoorlie,WesternAustralia, pp: 137-144. [13]Monjezi, M., & Rezaei, M. (2011). Developing a new fuzzy model to predict burden from rock geomechanical properties. Expert Systems with Applications, 38(8), 9266–9273. https://doi.org/10.1016/j.eswa.2011.01.029 [14]Rezaei, M., Monjezi, M., Ghorbani Moghaddam, S. et al. Burden prediction in blasting operation using rock geomechanical properties. Arab J Geosci 5, 1031–1037 (2012). https://doi.org/10.1007/s12517-010-0269-0 [15]Sri N. Chandrahas, B.S. Choudhary, N.S.R. Krishna Prasad,V. Musunuri, K.K. Rao, An Investigation into the Effect of Rockmass Properties on Mean Fragmentation. Arch. Min. Sci. 2021, 66, 561–578. [16]N. S. Chandrahas, B. S. Choudhary, and M. S. Venkataramayya, “Competitive algorithm to balance and predict blasting outcomes using measured field data sets,” Computers & Geosciences, vol. 27, pp. 1087–1110, 2023. [Online]. Available: https://doi.org/10.1007/s10596- 023-10254-x [17]M. Naresh, N. S. Sri Chandrahas, G. Praful Kumar, et al., “Harmonizing blasting efficiency: A case study on evaluation and optimization of fragmentation size and ground vibration,” Journal of the Institution of Engineers (India): Series D, 2024. [Online]. Available: https://doi.org/10.1007/s40033-024-00730-8 [18]Rezaei, M., Monjezi, M., Matinpoor, F., Mohammadi Bolbanabad, S., & Habibi, H. (2023). Simulation of induced flyrock due to open-pit blasting using the PCA–CART hybrid modeling. Simulation Modelling Practice and Theory, 129, 102844. https://doi.org/10.1016/j.simpat.2023.102844 [19]Cunningham, C.V.B. (1987) Fragmentation Estimations and the Kuz-Ram Model—Four Years on. In: Fourney, W.L. and Dick, R.D., Eds., Second International Symposium on Rock Fragmentation by Blasting, Keystone, Colorado, Bethel CT: SEM, 475-487. [20]Pradeep, T., Chandrahas, N. S., & Fissha, Y. (2024). A Principal Component-Enhanced Neural Network Framework for Forecasting Blast-Induced Ground Vibrations. J. Civ. Hydraul. Eng., 2(4), 206-219. https://doi.org/10.56578/jche020402 [21]N. S. Chandrahas, Y. Fissha, B. S. Choudhary, B. Olamide Taiwo, M. S. Venkataramayya, and T. Adachi, “Experimental data-driven algorithm to predict muckpile characteristics in jointed overburden bench using unmanned aerial vehicle and AI tools,” International Journal of Mining, Reclamation and Environment, pp. 1–35, 2024. https://doi.org/10.1080/17480930.2024.2340876 [22]Chandrahas, N.S., Choudhary, B.S., Venkataramayya, M.S. et al. An Inventive Approach for Simultaneous Prediction of Mean Fragmentation Size and Peak Particle Velocity Using Futuristic Datasets Through Improved Techniques of Genetic XG Boost Algorithm. Mining, Metallurgy & Exploration 41, 2391–2405 (2024). https://doi.org/10.1007/s42461-024-01045-8. [23]Sri Chandrahas; Bhanwar Singh Choudhary; MS Venkataramayya; Yewuhalashet Fissha; Blessing Olamide Taiwo. “An investigation of the cumulative impact of decking length and firing pattern on blasting results”, Journal of Mining and Environment , 2024, -. doi: 10.22044/jme.2024.14555.2743. [24]N. S. Chandrahas, B. S. Choudhary, M. S. Venkataramayya, Y. Fissha, and N. R. Cheepurupalli, “AI-driven analysis of rock fragmentation: The influence of explosive charge quantity,” Acadlore Trans. Geosci., vol. 3, no. 3, pp. 123–134, 2024. https://doi.org/10.56578/atg030301. [25]Chiappetta, R.F., Borg, D.G. & Sterner, V.A. (1987). Explosives and rock blasting. Atlas Powder Company,Dallas, pp:233. [26]Frimpong, M., Kabongo, K., & Davies, C. (1996). Diggability in a measure of dragline effectiveness and productivity. Proceedings of the 22nd Annual Conference on Explosives and Blasting Techniques, 95-104. [27]Abd Elwahab, A., Topal, E., & Jang, H. D. (2023). Review of machine learning application in mine blasting. Arabian Journal of Geosciences, 16(2), 133. [28]Rajwar, K., Deep, K., & Das, S. (2023). An exhaustive review of the metaheuristic algorithms for search and optimization: taxonomy, applications, and open challenges. Artificial Intelligence Review, 1-71. [29]Lee, K. S., & Geem, Z. W. (2005). A new meta-heuristic algorithm for continuous engineering optimization: harmony search theory and practice. Computer methods in applied mechanics and engineering, 194(36-38), 3902-3933. [30]Desale, S., Rasool, A., Andhale, S., & Rane, P. (2015). Heuristic and meta-heuristic algorithms and their relevance to the real world: a survey. Int. J. Comput. Eng. Res. Trends, 351(5), 2349- 7084. [31]Zhang, S., Ma, X., & Yan, J. (2018). Effects of Blast Design Parameters on Fragmentation in an Open Pit Mine. Mining, Metallurgy & Exploration, 35(3), 415-425. [32]Bhandari, S. (1975). Burden and Spacing Relationship in the Design of Blasting pattern. 16th Symp. Rock Mechanics, University of Minnesota, pp 333-343 [33]Sandeep Prasad, B.S. Choudhary, A.K. Mishra. Effect of Blast Design Parameters on Blast Induced Rock Fragmentation Size – A Case Study. Int. Conf. on Deep Excavation, Energy Resources and Production DEEP16 24-26 January 2017, IIT Kharagpur, India [34]Smith,N.S.(1976). An investigation of the effects of blast hole confinement on generation of ground vibration in bench blasting, Final report for blasting research, SMI grant section, p.301. [35]Zhang, Z. X., Qiao, Y., Chi, L. Y., & Hou, D. F. (2021). Experimental study of rock fragmentation under different stemming conditions in model blasting. International Journal of Rock Mechanics and Mining Sciences, 143, 104797. [36]Wu, Q., Huang, Y., & Tang, C. (2019). Effects of Joint Spacing on Rock Fragmentation and Muck Pile Characteristics in Open-Pit Mining. Minerals, 9(9), 554. [37]Chen, Q., Zhang, Y., & Shi, X. (2017). Influence of Joint Orientation on Muck Pile Fragmentation under Blasting. International Journal of Mining Science and Technology, 27(5), 833-838. [38]Cundall, P.A. (1990). Numerical modelling of jointed and faulted rock. In: Rossmanith HP (ed) Mechanics of jointed and faulted rock. A.A. Balkema, Rotterdam. [39]Belland, J.M. (1968). Structure as a Control in Rock Fragmentation Coal Lake Iron Ore Deposited. The Canadian Mining and Metallurgical Bulletin. 59 (647), 323-328. Li, Q., Liu, S., & Wang, Y. (2021). Effects of Bedding Plane Orientation on Particle Size Distribution and Shape of Muck Pile Fragmentation. Advances in Civil Engineering, 2021, 6651309.
