This paper presents the design and performance analysis of a compact rectangular microstrip patch Yagi-Uda antenna for amateur radio (HAM) applications operating at 5.75 GHz in the ultra-high frequency (UHF) band. The proposed antenna is fabricated on the RT/Duroid 5880 substrate with a dielectric constant of 2.2, thickness of 1.575 mm and loss tangent of 0.0009 with low dielectric losses and high radiation efficiency. The antenna design consists of a driven element, a reflector and five directors. Simulation is carried out using CST Microwave Studio and the optimized antenna shows a return loss of -62.24 dB, VSWR near to unity (1), a gain of 8.39 dBi, a beamwidth of 59.7° and an efficiency of 89.62% at the resonant frequency of 5.75 GHz. The antenna offers a bandwidth of 200 MHz (5.65-5.85 GHz) with stable radiation characteristics, making it highly suitable for compact HAM radio transceivers and UHF communication systems.

A compact 65x120mm2of microstrip patch Yagi-Uda antenna is designed at 5.75GHz for amateur radio applications. The RT/Duroid 5880 substrate is used with a dielectric constant of 2.2 and height of 1.575mm. The proposed antenna contains a driven element, 5 directors and a reflector. Only five directors used in this design. Because when 6th director was designed, due to the impedance mismatch, the gain value started decreasing. An electromagnetic solver software called CST Microwave Studio is used to study the performance of the simulated results. The designed antenna produced a gain of 8.39 dBi, Directivity of 8.86 dBi, Return Loss of -62.24 dB, VSWR of 1.001 and beamwidth of 59.7˚ at center frequency. 200 MHz (5.65 GHz to 5.85 GHz) of Bandwidth is covered. The side lobe level is -20.8 dB and achieved efficiency is 89.62%. The future work will be fabricating and testing of the proposed antenna. Also, the comparison between the simulated and fabricated work for further improvement.

1.A. Mukherjee, “Understanding relevance of amateur/ham radio in India,” RUDN Journal of Media, Communications and Cultural Studies, vol. 16, no. 4, pp. 1-14, 2024. 2.V. R. Karthic, “Voices in the Storm: The Crucial Role of Amateur Radio in Disaster Management and Mitigation in Tamil Nadu,” 2024. 3.D. Mohan, “Amateur radio advanced digital communication network in emergency applications,” ACWR ’11 Proc., 2011. 4.“Amateur radio good option for emergency communication,” The Tribune (India), Oct 31, 2023. 5.“Review on trends and recent development on Yagi-Uda antennas,” International Journal of Scientific & Research Publications (IJSRA), vol. 12, no. 4, pp. 1-8, 2024. 6.R. Singh, P. Mehra, and A. Sood, “A Broadside Yagi-Uda Antenna with Enhanced Gain for mm-Wave Applications,” International Journal of Infrared and Millimeter Waves, vol. 46, no. 3, pp. 215–225, 2025. 7.J. Zhang, L. Chen, and Y. Wang, “Screen-Printed 1×4 Quasi-Yagi–Uda Antenna Array on Highly Flexible Transparent Substrate for Emerging 5G Applications,” Electronics, vol. 14, no. 14, p. 2850, 2025. 8.A. Khan and M. Rahman, “Compact Multilayer Yagi-Uda Based Antenna for IoT/5G Sensors,” Sensors, vol. 22, no. 9, pp. 1–10, 2023. 9.S. Johansson and K. Lee, “Radiation Efficiency and Gain Bounds for Microstrip Patch Antennas,” arXiv preprint, arXiv:2403.18844, 2024. 10.N. Patel, D. Singh, and R. Verma, “Enhanced Performance of Microstrip Antenna Fabricated on a Composite Dielectric Substrate Coupled with Multiple Dielectric Superstrates,” Optical and Quantum Electronics, vol. 56, no. 8, 2024. 11.M. Ibrahim, S. Alhassan, and A. Okafor, “A Compact Quasi-Yagi Microstrip Patch Antenna with High Gain and Bandwidth for UWB Applications,” International Journal of Electronics and Telecommunications (IJET), vol. 69, no. 3, pp. 321-328, 2024. 12.T. Roberts, “Recent Innovations in Microstrip Patch Antennas: Biomedical Uses and Wireless Integration,” Applied Physics Reviews, vol. 12, no. 2, 2025. 13.P. Sharma, “A Literature Review on Yagi-Uda Antenna: Old but Still Used in Communities,” International Journal of Research and Scientific Innovation (IJRSI), vol. 12, no. 1, pp. 85-90, 2025. 14.D. Mehta, S. Pandey, and A. Jain, “Efficient 5.8 GHz Microstrip Antennas for Intelligent Transportation Systems: Design, Fabrication, and Performance Analysis,” Mathematics, vol. 12, no. 8, p. 1202, 2024. 15.A. Anisha and S. Enoch, “Analysis and design of microstrip patch antenna for S-band applications,” 2014 International Conference on Control, Instrumentation, Communication and Computational Technologies (ICCICCT), Kanyakumari, India, 2014, pp. 1101-1104, doi: 10.1109/ICCICCT.2014.6993125. 16.Warren L. Stutzman, Gary A. Tiele, “Antenna Theory and Design”, John Wiley & Sons, Inc, 1997. 17.Webinar Report on “HAM Radio Communication During Emergencies,” by National Institute of Disaster Management, Dated 20th May, 2022. 18.N. J. Shimu and A. Ahmed, “Design and performance analysis of rectangular microstrip patch antenna at 2.45 GHz,” 2016 5th International Conference on Informatics, Electronics and Vision (ICIEV), Dhaka, Bangladesh, 2016, pp. 1062-1066, doi: 10.1109/ICIEV.2016.7760161. 19.Payal, Madhusudhan R Goud and Komalpreet Kaur. Article: Design of Yagi-Uda Antenna using Microstrip Circuit. International Journal of Computer Applications 96(24):15-18, June 2014. 20.Kiran R. Rathod, Vijay S. Rasal, Sandesh S. Sawant and Vighnesh R. Mane, “Design and Fabrication of VHF Yagi Uda antenna for Durdrishti Ground Station,” International Journal of Emerging Technologies and Innovative Research (www.jetir.org), ISSN:2349-5162, Vol.6, Issue 6, page no.305-307, June 2019. 21.Prateek Khurana and Rajat Arora, “Comparative simulation of Yagi-Uda Microstrip Patch Antenna in C-Band and X-Band,” Middle-East Journal of Scientific Research 22 (12): pp.1795-1799, 2014. J. Kaur, N. Rani, A. Singh, V. Singh, R. Kaur and E. Sidhu, “Design and performance analysis of high gain flexible yagi microstrip patch antenna for fixed-satellite, radio location and amateur-satellite service applications,” 2017 Progress In Electromagnetics Research Symposium – Spring (PIERS), St. Petersburg, Russia, 2017, pp. 948-652, doi: 10.1109/PIERS.2017.8261880.
