This paper presents the design, simulation, and hardware implementation of a single-phase seven-level cascaded H-bridge multilevel inverter (CHBMLI) for medium-power applications. The proposed topology utilizes three H-bridge cells with isolated DC sources of 76V, 152V, and 230V derived from a multi-tap transformer through bridge rectifiers, synthesizing a seven-level stepped AC output waveform. A fundamental frequency switching scheme based on the equal area criteria (EAC) is employed to determine optimal switching angles (α₁ = 25.71°, α₂ = 51.42°, α₃ = 77.14°), which significantly reduces low-order harmonics and total harmonic distortion (THD). An Arduino Nano microcontroller generates the switching signals, which are amplified by TLP350 optocoupler-based gate driver circuits to control twelve IGBT switches (GW38IH130D). The hardware prototype delivers 230V AC output at 1.5A (345W) with a measured THD of [X]%, substantially lower than conventional two-level inverters. Simulation studies conducted in MATLAB/Simulink validate the theoretical analysis and show good agreement with experimental results. The modular topology offers several advantages including reduced voltage stress on power switches, lower electromagnetic interference, improved power quality, and scalability for higher voltage levels. A detailed comparative analysis demonstrates the superiority of the proposed design over conventional topologies in terms of harmonic performance and efficiency. Potential applications include renewable energy systems (solar PV and wind power integration), variable frequency motor drives, uninterruptible power supplies, and grid-connected systems. This work demonstrates that the seven-level CHBMLI provides an effective, low-cost solution for high-quality power conversion with minimal harmonic distortion, making it suitable for both educational and small-scale industrial applications.

This paper presented the design, simulation, and hardware implementation of a 7-level cascaded H- bridge multilevel inverter. The proposed topology successfully generates a seven-level output voltage using three H-bridge cells with isolated DC sources of 76V, 152V, and 230V. The equal area criteria switching technique with optimal angles (α₁=25.71°, α₂=51.42°, α₃=77.14°) significantly reduces total harmonic distortion. Simulation results validate the theoretical analysis, and hardware implementation confirms the generation of 230V AC output at 345W with substantially lower THD compared to conventional inverters. The modular design offers reduced voltage stress on switches, lower electromagnetic interference, and improved power quality. This work demonstrates that the 7-level CHB inverter provides an effective, low-cost solution for renewable energy systems, motor drives, and industrial applications requiring high- quality power conversion.

[1]. J. Rodriguez, J. S. Lai, and F. Z. Peng, “Multilevel inverters: A survey of topologies, controls, and applications,” IEEE Transactions on Industrial Electronics, vol. 49, no. 4, pp. 724-738, Aug. 2002. [2]. L. G. Franquelo, J. Rodriguez, J. I. Leon, S. Kouro, R. Portillo, and M. A. M. Prats, “The age of multilevel converters arrives,” IEEE Industrial Electronics Magazine, vol. 2, no. 2, pp. 28-39, June 2008. [3]. M. Malinowski, K. Gopakumar, J. Rodriguez, and M. A. Perez, “A survey on cascaded multilevel inverters,” IEEE Transactions on Industrial Electronics, vol. 57, no. 7, pp. 2197-2206, July 2010. [4]. S. Kouro, M. Malinowski, K. Gopakumar, J. Pou, L. G. Franquelo, B. Wu, J. Rodriguez, M. A. Perez, and J. I. Leon, “Recent advances and industrial applications of multilevel converters,” IEEE Transactions on Industrial Electronics, vol. 57, no. 8, pp. 2553-2580, Aug. 2010. [5]. F. Z. Peng and J. S. Lai, “Multilevel converters: A new breed of power converters,” IEEE Transactions on Industry Applications, vol. 32, no. 3, pp. 509-517, May/June 1996. [6]. A. Nabae, I. Takahashi, and H. Akagi, “A new neutral-point-clamped PWM inverter,” IEEE Transactions on Industry Applications, vol. IA-17, no. 5, pp. 518-523, Sept. 1981. [7]. E. Villanueva, P. Correa, J. Rodriguez, and M. Pacas, “Control of a single-phase cascaded H- bridge multilevel inverter for grid-connected photovoltaic systems,” IEEE Transactions on Industrial Electronics, vol. 56, no. 11, pp. 4399- 4406, Nov. 2009. [8]. K. K. Gupta and S. Jain, “A novel multilevel inverter based on switched DC sources,” IEEE Transactions on Industrial Electronics, vol. 61, no. 7, pp. 3269-3278, July 2014. [9]. J. Pereda and J. Dixon, “High-frequency link: A solution for using only one DC source in asymmetric cascaded multilevel inverters,” IEEE Transactions on Industrial Electronics, vol. 58, no. 9, pp. 3885-3892, Sept. 2011. [10]. A. Lashab, D. Sera, T. Kerekes, Y. Terriche, A. Bouzid, J. C. Vasquez, and J. M. Guerrero, “A cascaded H-bridge with integrated boosting circuit,” IEEE Transactions on Power Electronics, vol. 36, no. 1, pp. 18-22, Jan. 2021. [11]. S. K. Tummala, K. Hemalatha, I. H. Al-Kharsan, and V. Sajwan, “Performance of 7-level cascade H-bridge multi level inverter driven induction motor drive,” E3S Web of Conferences, vol. 472, p. 01003, 2023. [12]. R. B. Durgam, S. S. Rangarajan, S. Mohammad, K. S. Bairi, R. Thota, N. Yelthuri, and H. Nellutla, “Design of cascaded multi–Level inverter,” AIP Conference Proceedings, vol. 2971, no. 1, p. 1-13, 2024. [13]. P. V. V. R. Sharma and N. K. “A review on intelligence algorithms for THD minimization in multi-level inverter,” International Journal of Modelling and Simulation, pp. 1-17, 2024. [14]. H. Chadli, S. Chadli, M. Boutouba, M. Saber, and A. Tahani, “Hardware implementation and performance evaluation of microcontroller-based 7-level inverter using POD-SPWM technique,” Indonesian Journal of Electrical Engineering and Computer Science, vol. 23, no. 1, pp. 120-131, 2021. [15]. K. Saurabh, P. K. Lalabhai, A. Mankani, A. Chakraborty, A. Naugraiya, M. Tharun, S. Amal, P. D. Christain, and U. K. Baruah, “Modeling, Analysis, and Prototyping of a Cascaded HBridge Multilevel Inverter System Using TI F28379D Microcontroller for High-Voltage Applications,” in Fourth International Conference on Power, Control and Computing Technologies (ICPC2T), 2025, pp. 1-6. [16]. N. Kaushik and S. R, “A New Arduino Compatible Pulse Width Modulation Algorithm for a Five Level Inverter,” in 2025 3rd International Conference on Smart Systems for applications in Electrical Sciences (ICSSES), 2025, pp. 1-6. [17]. B. P. Mcgrath and D. G. Holmes, “Multicarrier PWM strategies for multilevel inverters,” IEEE Transactions on Industrial Electronics, vol. 49, no. 4, pp. 858-867, Aug. 2002. [18]. M. A. Perez, S. Bernet, J. Rodriguez, S. Kouro, and R. Lizana, “Circuit topologies, modeling, control schemes, and applications of modular multilevel converters,” IEEE Transactions on Power Electronics, vol. 30, no. 1, pp. 4-17, Jan. 2015.
