This project focuses on reducing drag caused by roll over vortices on aircraft wings. Roll over vortices increase turbulence, drag and reduce lift. A passive method is proposed to suppress these vortices using surface modifications on a NACA 2424 wing. Different modifications such as grooves, slits, notches and booms are analyzed. CFD analysis is carried out using ANSYS Fluent to study airflow and turbulence. Among all the modifications, the slit and groove show better vortex suppression. The modified wing is then fabricated and tested experimentally in a wind tunnel. Results show that the grooved wing reduces turbulence and suppresses vortices earlier than the normal wing. The grooved wing also increases the lift coefficient by nearly 20%. Thus, passive surface modification is an effective and simple method for drag reduction.

The present study investigated the suppression of rollover vortices on a NACA 2424 aerofoil using different passive suppressors such as wedges, grooves, booms and notches. The suppressors were placed at various positions on the wing surface and analysed using CFD tools. The results showed that passive suppressors are effective in reducing turbulence intensity and delaying flow separation over the aerofoil surface.Among all the suppressors considered, the groove-type suppressor provided better aerodynamic performance when compared with the normal wing and other suppressor configurations. The groove suppressor reduced the strength of rollover vortices, which in turn reduced drag and improved the lift characteristics of the aerofoil. The airflow remained attached to the wing surface for a longer distance, thereby decreasing the possibility of stall and vibration. The study also proved that passive techniques are simpler, less expensive and easier to implement than active flow-control methods. Since no external energy source is required, these suppressors can be practically applied to aircraft wings to improve aerodynamic efficiency. Therefore, the proposed method can be used as an effective solution for drag reduction and rollover vortex suppression in future aircraft design.

1.Raed I. Bourisli “Passive Drag Reduction Techniques for Modulating the Effects of Vortex Shedding” on International Journal of Materials, Mechanics and Manufacturing, February 2014. 2.P. W. Bearman and j. C. Owen department of aeronautics, imperial college, London sw7 2by,U.K “reduction of bluff-body drag and suppression of vortex shedding by the introduction of wavy separation lines” on journal of fluids and structures 1998. 3.Deepanshu Srivastav BE (Hons.) BITS Pilani, K K Birla Goa campus Zuarinagar Goa, India – 403726 “Flow Control over Airfoils using Different Shaped Dimples” on 2012 International Conference on Fluid Dynamics and Thermodynamics Technologies 2012 © (2012) IACSIT Press, Singapore 4.Karunakaran C.S School of Aeronautical Sciences, Hindustan University, Padur, Chennai, Tamil Nadu, India. “Study of Flow Field over Fabricated Airfoil Models of NACA 23015 with its Kline-fogleman Variant” on Advances in Aerospace Science and Applications 2013, © Research India Publications. 5.Karunakaran C.S School of Aeronautical Sciences, Hindustan University, Padur, Chennai, Tamil Nadu, India. “Study of Flow Field over Fabricated Airfoil Models of NACA 23015 with its Kline-fogleman Variant” on Advances in Aerospace Science and Applications 2013, © Research India Publications. 6.C. Lei,, L. Cheng, S.W. Armfield, K. Kavanagh, Department of Civil Engineering, The University of Western Australia, Perth 6907, Australia Department of Mechanical and Mechatronic Engineering, Sydney University, Sydney 2006, Australia on “Vortex shedding suppression for flow over a circular cylinder near a plane boundary” Ocean Engineering 2000. 7.S. Ozono, Department of Applied Physics, Miyazaki University, Miyazaki 889- 2192, Japan, “Vortex suppression of the cylinder wake by deflectors” on Journal of Wind Engineering and Industrial Aerodynamics 2003. 8.A. Dipankar, t. K. Sengupta and s. B. Talla department of aerospace engineering, iit Kanpur 208 016, India on “Suppression of vortex shedding behind a circular cylinder by another control cylinder at low Reynolds numbers” journal of fluid mechanics 2006, ©Cambridge university press. 9.P.J.Strykowski and K.R.Sreenivasan, Department of Mechanical Engineering, University of Minnesota, Minneapolis, MN 55455, USA, Mason Laboratory, Yale University, New Haven, CT 06520, USA, on “On the formation and suppression of vortex shedding at low Reynolds numbers” Journals of Fluid Mechanics 1990. 10.Wei-Xi Huang, Hyung Jin Sung Department of Mechanical Engineering, Korea Advanced Institute of Science and Technology, 373-1 Guseong-dong, Yuseong- gu, Daejeon 305-701, Korea, on “Vortex shedding from a circular cylinder near a moving wall” on Journal of Fluids and Structures 2007.
